Aluminum foil composite material through electromagnetic induction heating sealing technology, is currently more advanced, popular non-contact sealing technology.Its made by the principle of electromagnetic induction sealing machine has increasingly become medicine, agricultural chemicals, oil, food, health food, beverage, cosmetic, chemical and other industries for plastic, glass and other non-metallic bottle of hermetic seal to the necessary equipment, high quality to promote products, enhance the quality of sealing performance, improve the purpose of the anti-theft security requirements.
According to the principle that metal objects generate huge eddy current and heat under the action of high-frequency electromagnetic field, the machine fuses the adhesive film of the lower layer of aluminum foil and fuses with bottle mouth through electromagnetic induction to achieve continuous and rapid non-contact sealing.
Precision Control
The control lever can adjust the height of the sealing head for more convenient operation.
Instant Heating
Seal the mouth by fusing aluminum foil and bottle mouth through instant heating.
Certified Motor
The motor adopts high-quality motor and has passed CE certification.
Adjustable Speed
Speed knob to adjust the transmission speed of the conveyor belt according to the actual operation status.
Wide Sealing Range
Sealing range 20-130mm can adjust freely for ideal sealing quality and efficiency.
Safety Protection
When failure occurs, conveyor automatically stops to achieve sealing and unsealing isolation.
Stepless Regulation
Conveyer belt adopts electronic stepless speed regulation based on voltage and current changes.
Electric Adjustment
The sensor head height is adjusted by electric adjustment, for objects 40 ~ 400 mm high.
Name
Sealing machine for aluminum foil cup
Product Material
304 Stainless Steel
Power Supply
220V 2.2kw
Capacity
20-50 bottles per minute
Type of Cooling
Forced air cooling
Weight
30kgs
Machine Size (mm)
900x450x500mm
Characteristic
Stably and efficiently
1. What is the adjustable sealing range of this machine?
The machine features a flexible sealing range from 20mm to 130mm, which can be adjusted freely to meet various bottle mouth requirements.
2. Can the machine handle different bottle heights?
Yes, the sensor head height can be electronically adjusted to accommodate sealable objects ranging from approximately 40mm to 400mm in height.
3. How does the cooling system work?
The machine utilizes a forced air cooling system to maintain stable internal temperatures during continuous, high-speed operation.
4. What material is used for the machine construction?
The machine is constructed from high-quality 304 stainless steel, ensuring durability, hygiene, and resistance to corrosion.
5. Is the conveyor speed adjustable?
Yes, the conveyor belt uses electronic stepless speed regulation, allowing you to synchronize the transmission speed with the heating process for optimal results.
6. What happens if there is a failure during operation?
The machine is equipped with an automatic safety feature that stops the conveyor if a failure occurs, ensuring isolation between sealed and unsealed products.
